High frequency magnetic induction metal heating machine with induction coil

Product Description
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil
1. Brief introduction of high frequency induction heating machine
Our high frequency induction heating machine adopts IGBT series and parallel induction heating technology as the core. The induction heating machine heats the work piece to a certain temperature, and then cools it rapidly to change its machine structure to achieve some special mechanic properties.
2. Applications of high frequency induction heating machine
(1) Heat treatment: metal heating, quenching, annealing, tempering partly or wholly;
(2) Thermoforming: metal forging, hot forging, hot rolling partly or wholly;
(3) Welding: cutter blade, serrated blade, alloy cutter, steel tube, copper tube, dissimilar metal welding or brazing;
(4) Melting: gold, silver, copper, iron, aluminum and other metals melting, cast molding and evaporation coating.
Heating

High Frequency Magnetic Induction Metal Heating Machine with Induction Coil

Brazing / Welding
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil
Quenching / Hardening
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil
3. Features of high frequency induction heating machine

(1) High efficiency: Metal can be heated to its desired temperature, even its melting point, instantly.
(2) Energy saving: The induction heating machine adopts IGBT from Siemens & LC series circuit design, saving energy up to 15%-30%.
(3) Low cost: The heating time is short, compared to other heating methods, significantly reducing the amount of metal loss.
(4) Easy for installation: Following the user manual, even non-professional persons can install the induction heating machine easily.
(5) Stable operation: complete protection, make customers have nothing to worry about.
(6) No harm to the environment: The induction heating machine uses electricity, producing little waste gas and water.

4. Main technical parameters of LSW-80 induction heating machine
ModelLSW-80
Power80kw
Input current130A
Voltage3-phase 380V, 50/60Hz or customized
Oscillation frequency18-35KHz
Duty cycle100%
Machine dimension600*480*1360mm
Packaging dimension800*500*580mm
Gross weight185kg

Packaging and Shipping
As for packaging:
1. Pack the induction heating machine with wrapping film for waterproof;
2. Put it into a standard exporting wooden case;
3. Put foam around it for shockproof;
4. Fasten the case with nails.
As for shipping:
1. If you have a shipper in China, we can send the induction heating machine to him or her for free.
2. If you want us to send the induction heating machine to you directly, we can send it to any main port of China promptly.
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil

Certifications
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil
High Frequency Magnetic Induction Metal Heating Machine with Induction Coil
Our service
Pre-sale service:
1. Immediate reply to your inquiry.
2. Experienced sales answer all questions in fluent English.
3. Customized design is available.
4. Detailed information of our products, and our company if needed.

After-sale service:
1. Technical support, or alternative accessories if necessary.
2. Freely guide installation, commissioning and test run.
3. One year's warranty. Once there is a trouble within one year, professional engineers and sales will be promptly appointed to help.

Company Profile
1. Zhengzhou Lanshuo Electronics Co., Ltd is located in Zhengzhou, Henan Province
2. 15-year experience in the R&D, production and sale of high frequency and medium frequency induction heating machines.
3. Leading products include high frequency induction heating machine, super audio frequency induction heating machine, CNC quenching machine tool, medium frequency induction melting furnace, open type water cooling tower, closed loop water cooling tower, water chiller, etc.
4. Our products have been exported to more than 40 countries all over the world.
5. We have senior engineers and technical researchers. Engineers are available to service overseas if needed.
If you are interested in our products, please feel free to contact us. We will offer you the best products and service.
