Stainless Steel Tube Stainless Steel Fin HVAC Heating and Cooling Water Coil


fin tube heating coil Features:

Tube sizes range from 7mm to 15.88mm. Materials include copper, aluminum, stainless steel, and others. This product is brazed or welded depending on the material and application.
Raw materialCopper tube (inner smooth or inner grooved): O.D. Φ 7, Φ 7.94, Φ 9.52,
Wall thickness:t=0.32-0.36
Bare, hydrophilic Al foil(green antibacterial hydrophilic Al foil or slica antibacterial Al foil )
Side plate: galvanized steel plate:t=0.82.0
Application1P 5P home air-conditioner, Bus air-conditioner, Center air-conditioner for household
Key processTube bending, Punching the fins, Tube expanding, Degreasing, Welding and assembling, Leakage test, Drying, (Bending), Inspection, Packing
Technical standardsSpecificationHoles distanceFin typeExpansion ability
 Φ 721×12.7
isoceles triangle shape
V wave fin, Slit fin, louver fin6Rows, 36Holes
L: 1800mm(max)
Fin pitch:1.2 1.9
 Φ 7.9422×19.05
equilateral triangle shape
V wave fin,Louver fin4R, 36H
L: 1200mm(max)
Fin pitch:1.2 2.0
 Φ 9.5225×21.65
equilateral triangle shape
Flat fin, Slit fin, V wave fin6R, 44H
L: 2500mm(max)
Fin pitch:1.2 2.0
PerformanceCan satisfy the capability requirements
Capacity4.0 million sets per year (12500sets per day)
Residual moisture≤ 25 /
Residual impurity≤ 30 /
R134a Cooling System Tube Inside Standards

Our Advantages for fin tube heating coil:
1) Professional manufacturer, ROHS, BV, SGS, CE
2) Three- step Quality control. Inspect the raw material, unfinished products and finished products.
3) Experienced technical staff. We have senior engineers and technicians more than 20 people with many years of experiences.
4) More than 10 years' experiences of manufacturing. Cooperate with many famous brands: Midea, Gree, TCL, LG, Samsung, Hitachi, Panasonic etc.
5) Our products can be customized. We can produce for clients according to the sample or drawings.
6) Very competitive price with high quality products and perfect delivery date.

fin tube heating coil Tools list:
Fin
Type
Copper Tube
O.D.
(mm)
Row Space
(mm)
Hole Space
(mm)
Fin Thickness
(mm)
Fin Space (mm)
Flat finSine wave
with blade fin
Smooth sine
wave fin
Window finSesamoid fin
A712.7210.105//1.31.3/
B713.217.60.105//1.31.3/
C712.720.40.105//1.3~1.81.3~1.8/
D7.9415.8825.40.1051.8~3.01.8~3.01.8~3.01.8~3.0/
E7.9419.05220.105~0.131.4~3.01.4~3.01.4~3.01.4~3.0/
E9.522225.40.105~0.151.6~3.21.6~3.21.6~3.21.6~3.2/
F9.522225.40.18~0.43.5~6.35////
G9.5221.65250.105~0.181.6~3.21.6~3.21.6~3.21.6~3.2/
H9.5221.65250.15~0.243.2~6.353.2~6.353.2~6.35//
I12.7527.531.750.115~0.151.5~3.51.5~3.51.5~3.51.5~3.51.6~3.2
J15.883338.10.115~0.151.5~4.01.5~4.01.5~4.0//
K15.8834.64400.115~0.15/2.6~3.52.6~3.5//

fin tube heating coil fin type:
Stainless Steel Tube Stainless Steel Fin HVAC Heating and Cooling Water Coil

Stainless Steel Tube Stainless Steel Fin HVAC Heating and Cooling Water Coil

Stainless Steel Tube Stainless Steel Fin HVAC Heating and Cooling Water Coil
Aluminum Fins Evaporator application:

Stainless Steel Tube Stainless Steel Fin HVAC Heating and Cooling Water Coil
