Main characteristics
1. Siemens IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost. Small size, light weight
2. Fast Heating
3. Low Frequency suitble for hot forging application
4. Continuously heating ability for 24 hours.
5. Low power consumption, with electromagnetic grinding capability, providing uniform heating.
6. Induction heating machine adopts solid state IGBT frequency conversion control technologies, it has all kinds of protection control, giving signal under condition of over current, water shortage, overheating, over voltage, short circuit and so on, as a result, the reliability is greatly enhanced!
7. It has the function display of current, voltage, and timing, making the working condition easily perceived, and giving guidance to induction coil design, capacitance control.
2. Specification
Type | MF-45KW |
Work power | 3×380V/415V,440V,480V( 50-60hz) |
The range of operating voltage | 340V-430V |
Output power | 45 KW |
Working Capacity ( diamater) | 10-60MM |
Input current | 67A |
Timing (Heat time, Retain time , Cool time) | 1-99S |
Working Duty | 24hours withou stop |
Fluctuating frequency | 1-10KHZ |
The flow rate of cooling water | 0.08-0.16 Mpa 28L/Min |
Water temperature protection point | 40ºC |
Duty cycle | 100%(40degree room temperature) |
Weight: | Main parts: 65KG |
Forging Furnace Weight | About 110KG |
Size: | Main Parts: 650*550*360mm Extensive Parts: 1000*600*800mm |
Pre-sale service:
1. recommend the most suitable machine for customers, according to their requirements.
2. Inquiry and consulting support.
3. Sample testing support.
4. View our Factory.
In-sale service:
1. Strictly manufacture the machine, according to relevant technical standards.
2. Take run test, according to relevant equipment test run regulations.
3. Strictly check up the machine, before delivery
4. Delivery on time.
After-sale service:
1. Warranty time: Within 18 months from the date of delivering, 12months from date of receiving.
2. Within warranty all parts are free for customer, any fault caused by non-artificial reason, any quality problems such as design, manufacture, or procedure occurs, We shall provide replacement parts after detecting the faults.
3. If any big quality problems occurs out of the guarantee period, we will send maintenance
technician to provide visiting service after checking with the customer and charge for a favorable price.
5. We will provide a lifetime cost price to the buyer with the materials and spare parts used in system operation, equipment maintenance.
6. The above mentioned are only basic aftersale service requirements,we will make more promises related to quality assurance and operation guarantee.
